12" X 54" GANESH, 3-AXIS CNC VERTICAL MILLING MACHINE - " NEW "
or
Call (905) 669-7507
Specifications
| Manufacturer | GANESH |
| Model | GMV-4 |
| Stock Number | 4747 |
| TABLE SIZE | 12" X 54" |
| X-AXIS TABLE TRAVEL W/ CNC CONTROL | 33.5" |
| TABLE CAPACITY | 1,200 LBS. |
| TABLE TRAVEL - X-AXIS ( MANUAL ) | 34.75" |
| CROSS TRAVEL - Y-AXIS | 14" |
| KNEE TRAVEL | 16" |
| RAM TRAVEL | 17.7" |
| SPINDLE NOSE-TO-TABLE SURFACE TRAVEL | 2" - 18" |
| HEAD TILT ( LEFT TO RIGHT ) | 90º - 0 - 90º |
| HEAD TILT ( FRONT TO BACK / UP - DOWN ) | 45º - 0 - 45º |
| SPINDLE MOTOR | 5 HP |
| SPINDLE TAPER | NMTB #40 N.S. |
| VARIABLE SPPED DRIVE - LOW RANGE | 80 - 520 RPM |
| HIGH GEAR RANGE | 600 - 4000 RPM |
| QUILL TRAVEL - CNC Z-AXIS | 5" |
| QUILL DIAMETER | 4.13" |
| APPROX. WEIGHT | 3,600 LBS. |
| ELECTRICS | 220V/ 3/ 60 |
Equipped With
FAGOR CNC CONTROL
COOLANT SYSTEM
WORKLIGHT
PRECISION BALLSCREWS
HARDENED & GROUND BEDWAYS
CLASS 7 SPINDLE BEARINGS
MOTORISED KNEE TRAVEL
THIS MACHINE WAS PURCHASED NEW IN 2019 AND HAS NEVER BEEN USED, IT IS NEW CONDITION
