9-1/2" X 31-1/2", KNUTH, MILLING & DRILLING MACHINE
Sold
Specifications
| Manufacturer | KNUTH |
| Model | MARK SUPER S |
| Year | 2011 |
| Stock Number | 4517 |
| DRILLING CAPACITY | CAST IRON - 1.77" ( 45 MM ) / MILD STEEL - 1.25" ( 32 MM ) |
| FACE MILL CAPACITY | 3.15" ( 80 MM ) |
| END MILL CAPACITY | 1.25" |
| WORKING TABLE SIZE | 31-1/2" X 9-1/2" |
| CROSS TRAVEL | 9-1/2" |
| LONGITUDINAL TRAVEL | 22" |
| HEAD TILT LEFT RIGHT | 90° |
| SPINDLE TAPER | MT4 |
| MAX. DISTANCE SPINDLE TO TABLE | 18" |
| SPINDLE STROKE | 4.7" |
| MOTOR | 2 HP |
| ELECTRICS | 220V/3/60 |
| APPROX. WEIGHT | 700 LBS. |
Equipped With
2-AXIS KNUTH DIGITAL READOUT
AUTOMATIC QUILL FEED
NOTORIZED CUTTER HEAD MOVEMENT & HAND-WHEEL FOR EXACT POSITIONING OF HEAD
HAND WHEEL FOR QUILL MICRO-FEED
DIGITAL DEPTH INDICATOR FOR QUILL TRAVEL
HARDENED GEAR RACKS & SHAFTS FOR QUIET OPERATION & LONG LIFE
RIGID BASE WITH STORAGE
THIS MACHINE IS IN AS NEW CONDITION AND IS STILL ON ORIGINAL SHIPPING SKID.
