21" X 78" KIHEUNG , MODEL KMB-V-5, VERTICAL MILLING MACHINE
Specifications
| Manufacturer | KIHEUNG |
| Model | KMB-V-5 |
| Stock Number | 10097 |
| TABLE AREA | 21" X 78" |
| TABLE LOAD CAPACITY | 3,968 LBS. |
| LONGITUDINAL TRAVEL | 55" |
| CROSS TRAVEL | 24" |
| HEIGHT FROM TABLE TO VERTICAL SPINDLE NOSE | 2" - 27.5" |
| LONGITUDINAL & CROSS FEEDRATE | 0.63 - 78.74"/MIN. |
| VERTICAL FEEDRATE | 0.31 - 39.4"/MIN. |
| LONGITUDINAL & CROSS RAPID FEED | 126"/MIN. |
| VERTICAL RAPID FEED | 63"/MIN. |
| SPINDLE TAPER | NT50 |
| SPINDLE SPEED | 22 - 1400 RPM |
| DISTANCE FROM COLUMN TO VERTICAL SPINDLE CENTER | 23.6" |
| APPROX. WEIGHT OF MACHINE | 14,329 LBS. |
Equipped With
3 AXIS HEIDENHAIN DIGITAL READOUT
AUTOMATIC LUBRICATION
PENDANT CONTROL
THIS MACHINE HASE BEEN WELL CARED FOR AND IS IN GREAT CONDITION.
The KIHEUNG KMB-V-5 vertical milling machine is a robust and reliable choice for various milling tasks. This used model features a spacious table area of 21" x 78", which supports a load capacity of up to 3,968 lbs., making it ideal for handling large workpieces. It includes a 3-axis Heidenhain digital readout for precise adjustments and measurements throughout the milling process. The machine is equipped with automatic lubrication to enhance its operational lifespan and maintain optimal performance. This model supports a longitudinal travel of 55" and cross travel of 24", with feedrates ranging from 0.63" to 78.74" per minute for longitudinal and cross movements, and 0.31" to 39.4" per minute for vertical movements. Rapid feed speeds are 126" per minute for longitudinal and cross travels, and 63" per minute vertically, providing efficient and swift operation. The spindle, which is of NT50 taper, operates at speeds between 22 to 1,400 RPM, offering versatility for different materials and milling tasks. The spindle's height from the table ranges from 2" to 27.5", and the distance from the column to the vertical spindle center is 23.6", allowing flexibility in machining different sizes of workpieces. The machine is controlled via a pendant control system and weighs approximately 14,329 lbs., ensuring stability during heavy-duty milling operations. This milling machine is a solid investment for enhancing productivity in industrial settings.
