HEXAGON ABSOLUTE ARM V3P, 7 AXIS SCANNER AND PROBING

85 SERIES V3 7-AXIS ABSOLUTE ARM WITH 2.5m MEASUREMENT ARM

INCLUDES:

SCANNER + WIRELESS PACK + MAGNETIC BASE + PORTABLE BASE STATION + LAPTOP SUPPORT TRAY + GRAPHITE PORTABLE STAND + POWER SUPPLY HOLDER KIT +PC DMIS + LAPTOP W/ CAMERA AND WIFI

SPECIFICATIONS:

• Absolute Encoders and SMART Sensors

• Arm designed to IP54 standard for protection against dust

and moisture

• Zero-G Counterbalance

• SpinKnob and SpinGrip for improved operator comfort

• Haptic Feedback

• Wrist display

• Pistol Grips of 3 different sizes

• Fixed Base Plate

• Hook wrench for 4.5 inch base

• TESA TKJ Ball Probes: 3 mm Ruby / 6 mm Ruby / 15 mm

Steel

• Certified sphere artefact for accuracy checks

• RDS interface software

• Travel Case and IP54 protected Accessory Case

• Power supply

H00030938 AS1 Kit V2P

AS1 Laser Scanner for use with RA8 v2 and v3 7 axis

Absolute Arms (and Absolute Positioner AP21, used with

Laser Trackers).

Includes:

• AS1 Scanner unit with blue laser and SHINE technology,

mounted on the chosen 7 axis arm

• Designed to IP54 standard for protection against dust and

moisture (when mounted on the arm)

• Certificate of System Scanning Accuracy (arm and

scanner) to ISO 10360-8 Annex D

H00012444-01 CP-W

Wireless Pack (CP-W) shipped fully configured and mounted

on the arm.

The CP-W provides:

• Single Ethernet connection for all touch probes, tube

probes and scanners (HP-L-8.9, AS1, AS1-XL, and RS5).

• Wireless connections for all touch probes, tube probes

and scanners (AS1, AS1-XL, and RS5. HP-L-8.9 is not

supported).

• Ethernet to USB adapter, for users who prefer a USB

connection to Ethernet.

• Battery operation available (with hot-swappable batteries)

for use of the arm without connection to mains power

supply.

Includes:

• Wireless Pack CP-W

• ODU-Ethernet Cable - 3m

• Ethernet Gigabit adapter

• Two rechargeable batteries

Note: CP-W is certified to IP54 when mounted on the arm.

32378 Certified Length Standard - 711mm (28 inch)

Recommended for arm sizes of 2.0m and 2.5m.

H00042182 Magnetic Base with Mounting Ring 4.5"

Magnetic base for v3 Absolute Arms.

Includes:

• Base with 4.5 inch mounting ring on 3 magnetic blocks.

H00006816-02 Hexagon Dust Cover size 2.5m-3.0m

GB0005-2016 Hexagon Portable Base Station w/2 drawers - 910 x 610 mm

Ideal workplace for your portable arm measurement

includes:

• Swift-Fix Basic Kit

• M8 threaded, magnetic top plate with 50 mm hole pitch

• Convenient handle for easy movement

• Stable and robust construction made of steel and

aluminum

• Harmonized Hexagon Design

• Lockable drawers

• Stable and lockable wheels for smooth movement

• Dimensions (LxWxH): 910mm x 610mm x 935mm

• Package size: 111cm x 80cm x 115cm

• Net weight: 115kg

• Shipments are done from United Kingdom. Client is

responsible for all shipping charges.

GB0005-0045 Laptop Support Tray and Monitor Mount for Portable Base Station Quantity -1 No

• Mounted to the top surface and allows your notebook

computer to be raised above the workspace

• Adjustable height

• The platform tilts and includes protection features against

slipping

• Fits laptops up to 17"

• Vertical arm mount for an LCD monitor. The arm design

allows maximum side to side, in and out movement.

• Meets VESA standard 75x75mm and 100x100mm

GB0005-0026 Ratchet Jackable Castors Quantity - 1 No

Set of 4 ordered with a Base Station

BRUN-20178-4.5 Hexagon Stand, Graphite Portable Fixed - MGS 2000SF -4.5"-8 Ring

Quantity - 1 No

• Legs adjust from 24.37 in. to 38.25 in. (619 to 972mm).

• Net weight: 16 kg.

• Feet: 3 Pad feet included + Point feet

• Travel case sold separately.

• Supplied with 4.5in mounting ring for use with Absolute

Arm RA8v3

H00029348 Universal Power Supply Holder Kit Quantity - 1 No

Holds the Absolute Arm power supply unit so that it can be

attached to any stand, protecting it while the arm is in use. It

can be fixed to circular-section stand legs of up to 130mm

diameter or square-section legs.

Includes:

• Universal Power Supply Holder.

• 2x Cable Tie.

• Rubber straps for mounting.

ROY-SCANMESH PC-DMIS CAD++ Scanning / Mesh

Includes: All Portable interfaces (ROY-I-PORTABLE),

Hexagon Scanning Probe Interface, Scanning Auto

Features, Full COP support, XACT GD+T, IGES / DXF /

DWG / STEP203 / STEP 214 / VDAFS / XYZIJK / DES and

DMISI/O translators, STL Mesh Creation and Inspection,

and updates for 1 year. PC-DMIS provided with LMS license

62144-16 Premium Laptop - with Camera Bluetooth and WiFi Quantity - 1 No

Lenovo P Series or Equivalent with the following

recommended specs or better:

• PROCESSOR: 2.5 GHz 6 Core

• RAM: 64 GB

• DISK SPACE: 1 TB

• ETHERNET: Gigabit

• WI-FI: 802.11 ac

• GRAPHICS: Nvidia Quadro RTX A4400

• SCREEN: HD 1080p (1920x1080)

• Windows 10/11 Pro/Enterprise 64 bit
