50"X, 20"Y, 25"Z, HAAS, VF-4SS, W/ 5 AXIS TRUNION TABLE CNC VERTICAL MACHINING CENTER
or
Call (905) 669-7507
Specifications
| Manufacturer | HAAS |
| Model | VF4SS |
| Year | 2005 |
| Stock Number | 4679 |
| Electrics | 220V/3 PH/60 CY |
| Table size | 52" X 18" |
| Spindle motor | 30 HP |
| Spindle taper | BT 40 |
| X-axis travel | 50" |
| Y-axis travel | 20" |
| Z-axis travel | 25" |
| Approx. weight | 13,300 LBS. |
| Rapid feedrate | 1400 IPM |
| Spindle speeds | 12,000 RPM |
| Max. tool weight | 12 LBS. |
| Max. weight on table | 1,750 LBS |
| Max. cutting feedrate | 833 IPM |
| Spindle nose to table, max. | 29" |
| Spindle nose to table, min. | 4" |
Equipped With
Equipped with: HAAS CNC CONTROL
4/5 AXIS TRT 210 TRUNION TABLE 40 STATION SIDEMOUNT TOOL CHANGER RENISHAW PROBE
EXTRA Z CLEARANCE INLINE DIRECT DRIVE SPINDLE CHIP-AUGER USB REMOTE MPG
PROGRAMMABLE COOLANT
HIGH SPEED MACHINING
COORDINATE , ROTATION AND SCALING
MACRO OPTION
SPINDLE ORIENTATION
VISUAL QUICK CODE
THIS MACHINE IS IN VERY GOOD CONDITION AND CAN BE VIEWED UNDER POWER IN A PLANT
