HAAS, ST-25, 2021, CNC LATHE
Sold
Specifications
| Manufacturer | HAAS |
| Model | ST-25 |
| Year | 2021 |
| Stock Number | 4253 |
| Max. Part Swing | 21" |
| Max. Cutting Diameter | 11.75" |
| Max. Cutting Length | 22.5" |
| Bar Capacity | 3" |
| Travels - X-axis | 8.4" |
| Travels - Z-axis | 22.5" |
| Rapid Feedrate on X | 945 ipm |
| Rapid Feedrate on Z | 945 ipm |
| Max. Thrust X | 4100 lbf |
| Max. Thrust Z | 5100 lbf |
| Spindle Nose | A2-6 |
| Max. Rating | 30 Hp |
| Max. Speed | 3,400 rpm |
| Max. Torque | 300.0 ft-lbf @ 500 rpm |
| Spindle Bore | 3.5" |
| No. of Tools | 12 station |
| Boring Bar Rear Clearance (from back of turret ) | 4" |
| Coolant capacity | 55 Gal. |
| Approx. Weight | 9,000 lbs. |
Equipped With
Assorted Live Tools & Standard Holders
1GB Memory
Automatic tool presetter
Chip strainer
Coolant refill
Early power failure detection module
Ethernet
Haas Connect
High intensity lighting
Auto jet air blast
Belt type chip conveyor
BMT Turret
Live tooling
Macro option
Parts catcher system
Programmable tailstock
Rigid tapping
Spindle orientation
Visual programming system
WIFI Connection
This machine is in as new condition and still has approx 16 months Haas warranty on it.
